Description
DC EV Charger – Hero Series (60–480kW)
Experience the future of electric vehicle charging with the Hero Series DC Charger, engineered for performance, safety, and intelligent control. Designed to meet the demands of modern charging stations, this wall-mounted unit delivers ultra-fast and efficient charging with up to ≥95% efficiency.
Crafted from galvanized steel with a sleek and durable design, the charger offers power, intelligence, and convenience in one system.
Equipped with a 12.1-inch touch screen, Wi-Fi/4G/Ethernet connectivity, and RFID/app control, it ensures seamless interaction and real-time monitoring.
Specifications
| S.NO | PARAMETERS |
REQIREMENTS |
|
|
|
General Requirements |
||
|
1. |
Charger Capacity |
60 – 480 KW |
|
|
2. |
Model No. |
ENC-DCL060B |
|
|
|
Input Requirements |
||
|
3. |
AC Supply System |
Three-Phase, 5 Wire AC system (ENC) |
|
|
4. |
Nominal Input Voltage |
AC380V ±15% (ENC) |
|
|
5. |
Input Frequency |
50/60Hz |
|
|
Environmental Requirements |
|||
|
6. |
Ambient Temperature Range |
-25 to 55°C |
|
|
7. |
Ambient Humidity |
5 to 95% |
|
| 8. | Storage Temperature |
-40 to 70°C |
|
|
|
Mechanical Requirements |
||
|
9. |
IP Ratings |
IP 54 |
|
|
10. |
Cooling |
Air-cooled |
|
|
|
Output Requirements |
||
|
11. |
Number of Outputs |
2 •one gun charged,60kw max output •two guns charged, 30kw max each output |
|
|
12. |
Output Voltage |
DC 150-1000V |
|
|
13. |
Output Connector Compatibility |
IEC 62196 2017, IEC 61851 2017, SAE J1772, etc. |
|
|
14. |
Power Factor |
≥0.99 (50% load above) |
|
|
|
Communication Requirements |
||
|
15. |
Emergency Stop Switch |
Support |
|
|
16. |
Display |
21 INches Adv Screen & 21.1 inches touch screen with shell |
|
|
17. |
User Authentication |
Mobile Application or User Interface / QR Code / RFID Card / Password (Optional) |
|
|
18. |
Metering Information |
Consumption Units |
|
|
User Interface & Display Requirements |
|||
|
19. |
Communication between EVSE and Central Server |
OCPP 1.6J Protocol (Optional) |
|
|
20. |
Metering |
Grid Responsive Metering as Per Units’ Consumption of Each Vehicle |
|
|
21. |
Interface between charger and CMS |
Ethernet / 3G / 4G / WIFI (Optional) |
|
|
22. |
Safety Parameters |
Over Current, Under Voltage, Residual Current,Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc. |
|
