Description
A MODE 3 (IEC61851-1) FAST EV CHARGER FOR RESIDENTIAL and commercial USE
The smart EV charger has an IP55 patented design case for outdoor and indoor use.
The type 2 plug socket makes highly flexible and compatible with all electric vehicles.
FEATURES/ADVANTAGES
RFID card to charge automatically
Dual socket, Type 2 (IEC 62196-2)
Type A + DC6mA or Type B RCBO
Over Current Protection
Over Voltage & Under Voltage Protection
Over Temperature Protection
Lightning Protection
Contactor Adhesion Protection
Emergency Stop
SPECIFICATION
| Wallbox Models | BCPC-B2N-P | BCPC-BT2N-P | BCPC-D2N-P | BCPC-DT2N-P |
| Maximum Power | 7.4kW | 22kW | 2×7.4kW | 2x22kW |
| Input Voltage /Output voltage |
AC230 1-Phase | AC400 3-Phase | AC230 1-Phase | AC400 3-Phase |
| Input Frequency | 50/60Hz | |||
| Tethered/Socket | Socket | |||
| Meter | MID Meter | 2xMID Meter | ||
| Display | LCD Screen+LED Lights | |||
| RFID | ✓ | ✓ | ✓ | ✓ |
| DLB | ◯ | ◯ | ◯ | ◯ |
| Wi-Fi | ✓ | ✓ | ✓ | ✓ |
| Ethernet | ✓ | ✓ | ✓ | ✓ |
| Bluetooth | ✓ | ✓ | ✓ | ✓ |
| 4G | ◯ | ◯ | ◯ | ◯ |
| Over Voltage &Under Voltage Protection |
✓ | ✓ | ✓ | ✓ |
| Emergency Stop | ✓ | ✓ | ✓ | ✓ |
| Over Current Protection |
✓ | ✓ | ✓ | ✓ |
| CP Signal Short Circuit Protection |
✓ | ✓ | ✓ | ✓ |
| Over Temperature Protection |
✓ | ✓ | ✓ | ✓ |
| Lightning Protection | ✓ | ✓ | ✓ | ✓ |
| Contactor Adhesion Protection |
✓ | ✓ | ✓ | ✓ |
| Protection Degree | IP55 | IP55 | IP55 | IP55 |
| Environment Temperature |
-25℃~+50℃ |
|||
| Maximun Altitude | ＜2000m | |||
